Stock: Available
Price: Not Mension
Buy: In our Dubai shop. Out of Dubai, Call Us
Install: Taking as project
Brand: Fox Tech
Share This
Tweet- 1/3” SONY CCD, 420/540/650TVL
- 4-9mm / 5-15mm / 8-20mm auto focus lens (mega pixel)
- 360 degree Pan rotation, 90 degree tilt rotation, speed: 0.5 - 40 degree / second
- Min. Illumination: 0.01lux
- 128 preset points
- With RS485 Remote Control
- Memory function at accidental function
- Pelco D /P protocol
- Super wide voltage 8-18V CCD board design, low consumption
| Image Sensor | 1/3"SONY CCD |
| Digital Signal Processor | SONY DSP |
| Signal System | PAL / NTSC |
| Scanning System | 2:1 Interlace |
| Scanning Frequency(H) | NTSC:15.734KHZ , PAL:15.625KHZ |
| Sync. System | Internal |
| Horizontal System | 650TVL / 540TVL / 420TVL |
| Effective Pixels(HxV) | PAL:976x582 / PAL:752×582 / PAL:500×582 |
| Shuttle Speed | PAL=1/50 ~1/100,000 sec；NTSC=1/60 ~1/100,000 sec |
| Mini Illumination | 0.01 Lux |
| S/N Ratio | > 48dB（Auto Gain Off） |
| Gamma | 0.45 |
| White Balance | Auto |
| BLC | Open |
| Video Output | 1.0V P-P,75Ω |
| Control Mode | OSD Menu |
| LENS | 4-9/5-15/8-20MM sync focus lens |
| Rotation | Horizontal: 360°, Vertical 95°, Speed: 0-45°/s |
| Preset Position | 128 |
| Auto Cruise | 2 |
| Communication Mode | RS485 (PELCO-D/P Protocol) |
| Baut Rate | 2400/4800/9600BPS, Default: 2400 |
| Power Voltage | DC12V±10％ |
| Board Consumption | 70mA / 120mA / 80mA |
| Color | white |
